Cast Iron Valves
Cast Iron Y-Type Steam Strainer, Screwed (1MPa, KS Certified)
PriceOn request (see specifications)
KS
Specifications
| MODEL | ||
|---|---|---|
| Fluid | Water, liquid | |
| Max. working pressure | 1.0 MPa or less | |
| Max. temperature | 220℃ or less | |
| Hydrostatic test | Hydro. 1..5 MPa | |
| End connection | KS 0222 PT SCREWD | |
| Material | BODY | GC200 |
| TRIM | STS304 | |
Dimensions (unit: mm)
| SIZE | L | H |
|---|---|---|
| 15A | 80 | 58 |
| 20A | 95 | 69 |
| 25A | 110 | 84 |
| 32A | 135 | 99 |
| 40A | 160 | 115 |
| 50A | 185 | 144 |
Specification drawings
